40ft Dry Cooler 1.8MW

Antminer Bitcoin Miner 40-foot 1.8MW 304 Units for Antminer S19/S21 Series 1700KW Bitcoin Miner

Original price was: HK$570,252.00.Current price is: HK$570,040.00.

Guaranteed Safe Checkout

Features & Compatibility

Specification Name
Specification Value
Overall Dimensions (L×W×H) mm
6058×2438×2896
Server Capacity
other models
Enclosure Certification
China Classification Society (CCS) Certification
Safety Certifications
NFPA 79:2021; UL 508A:2018 R8.21; CSA C22.2 No.14-18; ANSI/ISO 12100:2012
Operating Power (kW)
1700±5
Input Voltage and Frequency
380-400V±10% 60Hz/50Hz
Transport Weight (T)
≈7
Main Circuit Breaker of Distribution Cabinet – Capacity (A)
2000 * 2
Rated Current (A)
≤1700
Standard Power (kW)
1680
Maximum Power (kW)
2000
Operating Power (kW)
1350
Rated Current per Unit (A)
≤10
External Interface (Dry Cooling Tower)
DN125 (Nominal Size 139.7-ISO 2852)
Flow Rate (m³/h)
≥144
Water-Cooled Container System Composition and Working Principle The container water-cooling system is designed to continuously provide coolant at the required pressure, temperature, and flow rate to the cooling units of high-computing-power servers, ensuring an optimal operating environment for the load. The container water-cooling system consists of two major modules: the container cabinet and the container cooling tower. The container cabinet is primarily used to house the water-cooled servers and houses the power distribution cabinet, CDU, and PLC control system. The container cooling tower circulates the internal cooling medium through the fins, with an upper fan to dissipate heat and cool the internal medium. The internal cooling medium can be selected from antifreeze, deionized water, or pure water, depending on the local ambient temperature.

Additional information

Dimensions 605 × 362 × 290 cm
